C71500 Copper Nickel 7030 (CDA 715)
Standards: ASTM B-151, ASTM B-122, DIN 2.0882
C70600 & C71500, Copper nickel offers excellent corrosion resistance, especially in marine salt water environments. The main, wrought copper-nickel alloys chosen for sea water service contain 10 or 30 percent nickel. They also have important additions of iron and manganese which are necessary to maintain good corrosion resistance. Some common applications for copper nickel include: valves, and pump components.
Equivalencies Copper Nickel (70/30) tube/pipe:
KS D5301 JIS H3300 | C7150T |
ASTM B111 | C71500 |
ASTM B466 | C71500 |
BS2871 {PART2} | CN107 |
AS1752 | C71500 |
DIN17664 | CuNi30Mn1FE |
DIN 86019 WL2.1972 | |
EEMUA 144 | |
MIL-T-16420K | 771506 |
EN12449 | CW354H |
Typical Uses for CDA 715 Copper Nickel "70/30":
INDUSTRIAL: Pump Impellers, Heat Exchanger Tubes, Evaporator Tubes, Distiller Tubes, Condenser Plates, Refrigerators, Process Equipment, Condenser Components, Ferrules, Welding Backing Rings, Flexible Metal Hose, Weld Wire, Boiler Parts, Condensers, Propeller Sleeves, Heat Exchanger Components
MARINE: Salt Water Flanges, Salt Water Piping, Valve Bodies, Sea Water Service, Fittings, Sea Water Condensers, Salt Water Pipe Fittings, Water Boxes - Salt Water Applications, Pump Bodies and Internal Parts-Sea Water
Sizes Available From NBM
SOLID BAR . . . . . . . . . . 1/4" - 12" diameter
PLATE . . . . . . . . . . . . . . . up to 6" thick
Specifications
End Product | Specification |
Bar | ASTM B122, B151, MILITARY MIL-C-15726, SAE J461, J463 |
Bolts | ASTM F468 |
Electrode, Welding | AWS A5.6, MILITARY MIL-E-22200/4 |
Nuts | ASTM F467 |
Pipe, Seamless | ASME SB466, ASTM B466 |
Pipe, Welded | ASTM B608, B467 |
Plate | ASTM B122, MILITARY MIL-C-15726, SAE J461, J463 |
Plate, Clad | ASTM B432 |
Plate, Condenser Tube | ASME SB171, ASTM B171, SAE J463, J461 |
Rod | ASTM B151, MILITARY MIL-C-15726 |
Screws | ASTM F468 |
Sheet | ASTM B122, MILITARY MIL-C-15726, SAE J463, J461 |
Strip | ASTM B122, MILITARY MIL-C-15726, SAE J461, J463 |
Studs | ASTM F468 |
Tube, Condenser | ASME SB111, ASTM B552, B111, MILITARY MIL-T-15005, SAE J463, J461 |
Tube, Finned | ASME SB359, ASTM B359, MILITARY MIL-T-22214 |
Tube, Seamless | ASME SB466, ASTM B466, MILITARY MIL-T-16420 |
Tube, U-Bend | ASME SB395, ASTM B395 |
Tube, Welded | ASME SB543, ASTM B543 |
Wire | MILITARY MIL-C-15726 |
-
-
-
*
-
-
*
-
