C10200 Oxygen Free Copper (CDA 102)
   C10200 Oxygen Free Copper (CDA 102)

UNS CDA 102, SAE J461, ASTM B152, ASTM B187, ASTM B272

High Conductivity (OFHC) Copper characteristics are high ductility, high electrical and thermal conductivity, high impact strength, good creep resistance, ease of welding, and low volatility under high vacuum.

TYPICAL USES FOR C10200 OXYGEN FREE COPPER:

ELECTRICAL: Electrical Conductors, Klystrons, Microwave Tubes, Transistor Components, Lead In Wire, Coaxial Cables, Copper to Glass Seals in Electronic Appliances, Busbars, Bus Conductors, Wave Guides

INDUSTRIAL: Tubing, LP Gas Service, Tubing, Medical Gas- Oxygen, Vacuum Seals, Coaxial Tube, Billet Mold Tube, Extrusion Cans for Powder Metallurgy


Description:

Sizes Available From NBM

RECTANGLES / FLAT BAR: 1/8" - 2" thick through 1/2" - 8" wide

SQUARE BAR: 1/4" - 2" Square

ROUND BAR: 3/16" - 15" Diameter

Specifications

End Product

Specification

Bands, Projectile Rotating

MILITARY MIL-B-20292, MIL-B-18907

Bar

AMS 4602, ASME SB152, SB133, ASTM B152, SAE J463, J461

Bar, Bus

ASTM B187, SAE J463, J461

Brazing Filler Metal

FEDERAL QQ-B-650

Fittings

ASME B16.22

Foil, Printed Circuits

ASTM B451

Nipples

ASTM B687

Pipe

ASME SB42, ASTM B698, B42

Pipe, Bus

ASTM B188

Plate

AMS 4501, ASME SB152, ASTM B152, SAE J463, J461

Plate, Clad

ASTM B432

Rod

AMS 4602, ASME SB152, ASTM B152, SAE J463, J461

Rod, Bus

ASTM B187

Shapes

AMS 4602, SAE J461, J463

Shapes, Bus

ASTM B187

Sheet

AMS 4501, ASME SB152, ASTM B152, SAE J461, J463

Sheet, Clad

ASTM B506

Sheet, Printed Circuits

ASTM B451

Strip

AMS 4501, ASME SB152, ASTM B152, SAE J461, J463

Strip, Clad

ASTM B506

Strip, Printed Circuits

ASTM B451

Tube

ASTM B698

Tube, Air Conditioning and Refrigeration Field Service

SAE J461, J463

Tube, Bus

ASTM B188

Tube, Coils

ASTM B743

Tube, Condenser

ASME SB111, ASTM B111

Tube, Finned

ASME SB359, ASTM B359

Tube, Rectangular Waveguide

ASTM B372, MILITARY MIL-W-85

Tube, Seamless

ASME SB75, ASTM B641, B75, MILITARY MIL-T-24107

Tube, Seamless Bright Annealed

ASTM B68

Tube, Seamless for Air Conditioning and Refrigeration Field Service

SAE J461, J463

Tube, Seamless for Torpedo Use

MILITARY MIL-T-3235

Tube, U-Bend

ASME SB395, ASTM B395

Tube, Welded

ASTM B716, B641, B447, MILITARY MIL-T-24107, SAE J461, J463

Tube, Welded for Air Conditioning and Refrigeration Service

ASTM B640

Wire, Coated With Lead Alloy

ASTM B189

Wire, Coated With Nickel

ASTM B355

Wire, Coated With Silver

ASTM B298

Wire, Coated With Tin

ASTM B33, B246

Wire, Flat

ASTM B272

Wire, Hard Drawn

ASTM B1, FEDERAL QQ-W-343

Wire, Medium-Hard Drawn

ASTM B2, FEDERAL QQ-W-343

Wire, Metallizing

MILITARY MIL-W-6712

Wire, Soft

AMS 4701, ASTM B3, B738, B48, F9, FEDERAL QQ-W-343

Wire, Stranded

ASTM B8, B174, B470, B172, B173, B286, B496, B226, FEDERAL QQ-B-575
