C23000 Red Brass (CDA 230 C230 230 Brass)

C23000 brass is the most durable of all metals for commercial water pipe in the practical price range. Excellent for its resistance to dezincification and season cracking for which the high copper brasses are known. Moderate strength and good retention of spring properties. Specified for underground service lines since it offers greatest corrosion resistance to all types of potable waters. Applications for C23000 brass include costume jewelry, fire hose couplings, zippers, condenser and heat exchanger tubes. Popular as an outdoor metal and has found for itself a very important place in modern architecture. Also known as Nordic Brass. The EN equivalent for this alloy is CuZn15.

Description:

Typical Uses for C23000 Red Brass:

ARCHITECTURE: Etching Parts, Weather Strip, Trim

ELECTRICAL: Sockets, Screw Shells, Conduit, Rotor Bars, AC Motors

FASTENERS: Fasteners, Eyelets

INDUSTRIAL: Heat Exchanger Shells, Flexible Metal Hose, Pump Cylinder Liners, Tags, Radiator Cores, Pickling Crates, Condenser Tubes, Fire Extinguishers, Tubing for Instrumentation, Tubing for Heat Exchangers, Heat Exchangers

BUILDERS HARDWARE: Kick Plates

PLUMBING: Fittings, Pump Lines, Pipe Service Lines, Pipe Nipples, Pipe, Service Lines, J-Bends, Traps

OTHER: Fire Hose Couplings


Specifications

End Product

Specification

Bar

ASTM B36

Fittings

ASME B16.29, B16.22

Nipples

ASTM B687

Pipe

ASME SB43, ASTM B698, B43

Plate

ASTM B36

Sheet

ASTM B36, SAE J461, J463

Strip

ASTM B888, B36, SAE J463, J461

Tube

ASTM B569, B698

Tube, Condenser

ASME SB111, ASTM B111

Tube, Finned

ASME SB359, ASTM B359

Tube, Seamless

AMS 4553, ASME SB135, ASTM B135, FEDERAL WW-T-791, MILITARY MIL-T-20168, SAE J461, J463

Tube, U-Bend

ASME SB395, ASTM B395

Tube, Welded

ASME SB543, ASTM B587, B543

Wire

ASTM B134
