C95900 Aluminum Bronze is characterized by its high strength and excellent corrosion resistance. This alloy is for heavier loads under abrasive conditions where impact is present. C95900 is an excellent heavy duty bearing alloy, and should be used against hardened steel shafts, with both shaft and bearing machined to fine surface finishes. Uses for CDA 959 is utilized in the tool and die and roll forming industries, and its applications include a variety of heavy duty mechanical and structural products including gears, worm drives, valve guides and seats.
Specifications
End Product | Specification |
Centrifugal | ASTM B271, SAE J462, J461 |
Continuous | ASTM B505/B505M, SAE J462, J461, QQ-C-390B Type III, MIL-B-16033 Class 4, SAE J461, BS1400 AB2 |
Ingot | ASTM B30 |
Precision | ASTM B806 |
Sand | ASTM B148, B763, SAE J461, J462 |
c95500 Chemical Composition
Al | Cu | Fe | Mn | Ni | |
Min/Max | 10.0-11.5 | 78.0 min | 3.0-5.0 | 3.5 | 3.0-5.5 |
Nominals | 11.0000 | 80.0000 | 4.0000 | - | 4.3000 |
